OL-F02-PD35 35W GaN Travel Adapter with 4 USB-C Ports and 2 AC Sockets

Model: OL-F02-PD35

USB-C1 delivers up to 35W. A compact travel adapter with four plug formats, four USB-C ports, one USB-A port and two AC sockets.

USB-C1 maximum output35W
USB ports4 × USB-C + 1 × USB-A
AC sockets2
Dimensions66 × 50 × 55mm
Plug formatsUS / AU / UK / EU

MOQ, sample availability and lead time are confirmed by model and project.

Request a Quote

The model is included in your inquiry.

01 / PRODUCT OVERVIEW

Product Overview

Slide-out US, AU, UK and EU plugs support travel charging in a compact body. The input socket includes a Type-D acceptance layout. A 10A ceramic fuse and spare fuse are shown in the supplied configuration. Black, white and pastel finishes provide product-range options. Check the destination mains voltage and appliance rating; the adapter does not convert AC voltage. Total USB output is limited to 35W across the connected USB devices.

02 / TECHNICAL SPECIFICATIONS

Specifications

Model-specific specifications and operating conditions.

Chargers technical specifications
Dimensions	66 × 50 × 55mm
USB ports	4 × USB-C + 1 × USB-A
AC sockets	2
AC load rating	10A; 1000W at 100V AC / 2500W at 250V AC
USB-C1 output	35W max.
USB-A1 output	5V / 2.4A; 12W max.
USB-C2/C3/C4 output	5V / 3A; 15W max.
Shared USB output	35W max.
Housing material	PC
Fuse	10A ceramic fuse with spare

03 / CUSTOMIZATION

Customization Options

Depending on the model and project, we can support functional and configuration changes, logo printing or laser engraving, packaging customization, and new product design & development.
